Niles Audio C5-SVA2 User Manual

C5-sva2

I N S T A L L A T I O N G U I D E

C5-SVA2

F O R P L A C I N G A / V D E V I C E S E X T E N D E D
D I S T A N C E S F R O M T H E I R A / V S O U R C E
C A T - 5 S - V I D E O S T E R E O A U D I O B A L U N

CONGRATULA

TIONS!

Thank you for choosing the

C5-SVA2 S-Video

Stereo Audio Balun

from Niles. With proper

installation and opera

tion, you’ll enjo

y years of trouble free use.

Niles manufacturers the industry’

s most complete line of custom installation components and

accessories for audio/video systems. To see the complete assortment,

visit our website at

www.nilesaudio.com.

INTRODUCTION

The C5-SVA2 is a stand-alone device tha

t transforms on S-Video channel and a pair of audio

channels to and from CAT-5 twisted pair cabling.

It has two sets of simple connections. The

ﬁrst is one S-Video a pair of RCA connectors for the S-Video and line level audio signals.

The

second is a shielded CAT-5 connector for the CA

T-5 twisted pair connection.

The circuitr

y is

passive so there is no need for a power supply

The C5-SVA2 allo

ws an S-Video and line-level audio device such as a VCR or Sa

tellite

Receiver to be located an extended distance from the system it is to be connected to.

Doing

so with conventional audio video cabling is both expensive and prone to signal degradation.

By using a pair of these devices and a run of CAT-5 the problem can be solved inexpensively

and without signal loss and the introduction of noise. Additionally

, in today’

s retroﬁt market an

installer cannot always successfully run a wire from point

A to point B. There exists ho

wever

an abundance of twisted pair cabling in many homes.

By using a pair of these devices with an

existing wire an installer may be able to complete a job that he otherwise could not.

FEATURES

• Shielded CAT-5 Connector

• Gold Plated Color Coded RCA Connectors

• Gold Plated S-Video DIN Connector

• Universal Mounting Holes

• Ten-y

ear limited warr

anty

SPECIFICATIONS

• Overall dimensions:

4.75" W x .85" H x 2" D

• Bandwidth:

Y: DC to 6 MHz

C: 1 MHz to 6 MHz

• Tr

ansmission Distance:

S-Video: 500' (150 m) (CA

T-5 UTP)
