Niles Audio C5-A2WM User Manual

C5-a2wm

I N S T A L L A T I O N G U I D E

C5-A2WM

FOR PLACING LINE LEVEL AUDIO DEVICES

EXTENDED DISTANCES FROM THEIR AUDIO SOURCE

C A T - 5 A U D I O S T E R E 0 W A L L M O U N T B A L U N

CONGRATULA

TIONS!

Thank you for choosing the

C5-A2WM Stereo Audio Balun from Niles.

With proper

installation and opera

tion, you’ll enjo

y years of trouble free use.

Niles manufacturers the industry’

s most complete line of custom installation components and

accessories for audio/video systems. To see the complete assortment,

visit our website at

www.nilesaudio.com.

INTRODUCTION

The C5-A2WM is a stand-alone device that transforms a pair of audio channels to and from

CAT-5 twisted pair cabling.

It has two sets of simple connections. The ﬁrst is a pair of RCA

connectors for the line level audio signals. The second is a shielded CA

T-5 connector for the

CAT-5 twisted pair connection.

The circuitr

y is passive so there is no need for a power supply

The C5-A2WM allows a line-level audio device such as a subwoofer or CD player to be loca

ted

an extended distance from the system it is to be connected to. Doing so with conventional

audio cabling is both expensive and prone to signal degradation.

By using a pair of these

devices and a run of CAT-5 the problem can be solved inexpensively and without signal loss

and the introduction of noise. In addition,

in today’s retroﬁt market an installer cannot al

ways

successfully run a wire from point A to point B.

There exists ho

wever an abundance of twisted

pair cabling in many homes.

By using a pair of these devices with an existing wire an installer

may be able to complete a job that he otherwise could not.

FEATURES

• Shielded CAT-5 Connector

• Gold Plated Color Coded RCA Connectors

• Ten-y

ear limited warr

anty

SPECIFICATIONS

• Overall dimensions:

1.75" (44.5 mm) W x 2.84" (7.2 mm) H x 1.99" (5 mm) D

• Cut out size: 1.87”

(47.5 mm) W x 3.00”

(76.2 mm) H x 2.50” (63.50 mm) D

• Bandwidth: 20 Hz – 20 kHz

• Tr

ansmission Distance: 2000' (CA

T-3 UTP),

2500' (CAT-5 UTP)

N i l e s A u d i o C o r p o r a t i o n

1 2 3 3 1 S . W . 1 3 0 S t r e e t M i a m i , F l o r i d a 3 3 1 8 6

3 0 5 - 2 3 8 - 4 3 7 3

1 - 8 0 0 - B U Y - H I F I w w w . n i l e s a u d i o . c o m

Blending High Fidelity and Architecture are registered trademarks of Niles Audio Corporation.

All other trademarks are the property of their respective owners. D S 0 0 5 7 6 A

L E N D I N G

I G H

I D E L I T Y

N D

R C H I T E C T U R E

• 1-Gang Decora Style

• Decora w

all plate included
