Chapter 6
Advanced Features
E-DOC-CTC-20051017-0169 v0.1
187
6.5.4 Attach the vpnserver entity to the peer entity
modify the peer
parameters
The
:ipsec peer modify name=peer1 client/server=serv1
command attaches the previously defined vpnserver entity to the corresponding
peer.
Example
In this example vpnclient1 is attached to peer1:
The result is shown when listing the peer entities:
[ipsec peer]=>modify
name = peer1
[remoteaddr] = 20.50.10.2
[backupaddr] =
[exchmode] = main
[localid] = (addr)20.60.10.2
[remoteid] = (addr)20.50.10.2
[phyif] = DIALUP_PPPOE
[descr] = AES_MD5
[auth] = secret1
[client/server] = serv1
[options] =
:ipsec peer modify name=peer1 client/server=serv1
[ipsec peer]=>
[ipsec peer]=>list
[peer1]
Remote Address
: 20.50.10.2
Backup Remote Address:
Physical IF
: DIALUP_PPPOE
Exchange Mode
: main
Local Identifier
: (addr)20.60.10.2
Remote Identifier
: (addr)20.50.10.2
Descriptors
: AES_MD5
Authentication
: secret1
Client/Server
:
VPN Client Descriptor: serv1
Options
:
[ipsec peer]=>
