Administrator’s Guide SoundPoint IP / SoundStation IP

A - 50

Call Control
These parameters apply to call control packets, such as the network protocol

signaling.

Basic TCP/IP

This attribute includes:

•

•

•

Attribute

Permitted
Values

Default

Interpretation

qos.ip.callControl.dscp

0 to 63 or
EF or
any of
AF11,AF12,
AF13,AF21,
AF22,AF23,
AF31,AF32,
AF33,AF41,
AF42,AF43

Null

This parameter allows the DSCP of
packets to be specified. If set to a
value this will override the other
qos.ip.callControl

…

parameters. Default of Null which
means the other
qos.ip.callControl

…

parameters will be used.

qos.ip.callControl.min_delay

0, 1

If set to 1, set min-delay bit in the IP
TOS field of the IP header, or else
don’t set it.

qos.ip.callControl.max_throughput

0, 1

If set to 1, set max-throughput bit in
the IP TOS field of the IP header, or
else don’t set it.

qos.ip.callControl.max_reliability

0, 1

If set to 1, set max-reliability bit in
the IP TOS field of the IP header, or
else don’t set it.

qos.ip.callControl.min_cost

0, 1

If set to 1, set min-cost bit in the IP
TOS field of the IP header, or else
don’t set it.

qos.ip.callControl.precedence

0-7

If set to 1, set precedence bits in the
IP TOS field of the IP header, or
else don’t set them.
