Supervisory contact module terminal locations – Powerware 9390 UPS 100160 kVA User Manual
Page 203
091505
A
DESCRIPTION:
DATE:
DRAWING NO:
SHEET:
REVISION:
INTERFACE WIRING INSTALLATION
NOTES AND TERMINAL LOCATIONS
TERMINAL TB–1
SIGNAL CONNECTIONS
FROM THE UPS
GROUND
TERMINAL
REMOTE MONITOR PANEL AND RELAY
INTERFACE MODULE TERMINAL LOCATIONS
TERMINAL TB–3
120 VAC POWER
SUPERVISORY CONTACT MODULE
TERMINAL LOCATIONS
GROUND
TERMINAL
TERMINAL TB–1
SIGNAL CONNECTIONS
FROM THE UPS
TERMINAL TB–3
120 VAC POWER
TERMINAL TB–2
CUSTOMER SUPERVISORY
CONTACT INTERFACE
14 of 15
INSTALLATION INFORMATION
EATON Powerware
®
9390 UPS (20–80 kVA) Installation and Operation Manual
S 164201603 Rev 2 www.powerware.com
A-55
