PHYSICAL FEATURES AND REQUIREMENTS
071608
C
DESCRIPTION:
DATE:
DRAWING NO:
SHEET:
REVISION:
INSTALLATION INFORMATION
EATON Powerware
®
9390 UPS (20–80 kVA) Installation and Operation Manual
S 164201603 Rev 2 www.powerware.com
A-3
1.
The UPS equipment operating environment must meet the weight requirements shown in
Table A and the size requirements shown on Drawing 164201603-9.
2.
The UPS cabinet is palleted separately for shipping.
3.
Do not tilt cabinets more than
"
10° during handling.
4.
Dimensions are in millimeters (inches).
5.
The cabinet can be installed in line‐up‐and‐match or standalone configurations.
Table A. UPS Cabinet Weight
Model
Voltage
Weight
kg (lb)
Input
Output
Shipping
Installed
Point Loading
Powerware 9390-40/20
208V/220V
208V/220V
231 (508)
208 (458)
4 at 52.2 (115)
380V/400V/
415V/480V
380V/400V/
415V/480V
Powerware 9390-40/30
208V/220V
208V/220V
231 (508)
208 (458)
4 at 52.2 (115)
380V/400V/
415V/480V
380V/400V/
415V/480V
Powerware 9390-40/40
208V/220V
208V/220V
231 (508)
208 (458)
4 at 52.2 (115)
380V/400V/
415V/480V
380V/400V/
415V/480V
Powerware 9390-80/40
208V/220V
208V/220V
313 (690)
290 (640)
4 at 72.5 (160)
380V/400V/
415V/480V
380V/400V/
415V/480V
271 (618)
258 (568)
4 at 64.5 (142)
Powerware 9390-80/50
208V/220V
208V/220V
313 (690)
290 (640)
4 at 72.5 (160)
380V/400V/
415V/480V
380V/400V/
415V/480V
271 (618)
258 (568)
4 at 64.5 (142)
Powerware 9390-80/60
208V/220V
208V/220V
313 (690)
290 (640)
4 at 72.5 (160)
380V/400V/
415V/480V
380V/400V/
415V/480V
271 (618)
258 (568)
4 at 64.5 (142)
Powerware 9390-80/80
208V/220V
208V/220V
313 (690)
290 (640)
4 at 72.5 (160)
380V/400V/
415V/480V
380V/400V/
415V/480V
271 (618)
258 (568)
4 at 64.5 (142)
