Drawing 164201603-7, Left side view, Right side view – Powerware 9390 UPS 100160 kVA User Manual
Page 183
2 of 2
CONDUIT AND WIRE ENTRY LOCATIONS
091505
A
LEFT SIDE VIEW
DESCRIPTION:
DATE:
DRAWING NO:
SHEET:
REVISION:
RIGHT SIDE VIEW
INTER‐CABINET WIRING ACCESS
KNOCKOUTS. REMOVE KNOCKOUTS,
AS REQUIRED, TO ROUTE WIRES
BETWEEN CABINETS.
INSIDE PANELS
INTER‐CABINET WIRING
ACCESS KNOCKOUTS.
REMOVE KNOCKOUTS, AS
REQUIRED, TO ROUTE WIRES
BETWEEN CABINETS.
INSTALLATION INFORMATION
EATON Powerware
®
9390 UPS (20–80 kVA) Installation and Operation Manual
S 164201603 Rev 2 www.powerware.com
A-35
