EATON Powerware ® 9390 UPS (20–80 kVA) Installation and Operation Manual S 164201603 Rev 2 www.powerware.com 14-1
Chapter 14 Product Specifications
14.1 Model Numbers
The UPS systems are housed in free‐standing cabinets with safety shields behind the
doors. The UPS systems are available in 50/60 Hz with various output power ratings.
Models Power Rating Frequency
Powerware 9390-40/20 20 kVA 50/60 Hz
Powerware 9390-40/30 30 kVA 50/60 Hz
Powerware 9390-40/40 40 kVA 50/60 Hz
Powerware 9390-80/40 40 kVA 50/60 Hz
Powerware 9390-80/80 50 kVA 50/60 Hz
Powerware 9390-80/80 60 kVA 50/60 Hz
Powerware 9390-80/80 80 kVA 50/60 Hz
The following sections detail the input, output, environmental, and battery
specifications for the UPS.
14.2 Single Module Specifications
14.2.1 UPS System Input
Operating Input Voltage
(Nominal +10/–15%) 208 Vac for operation from 177 Vac to 229 Vac
220 Vac for operation from 187 Vac to 242 Vac
380 Vac for operation from 223 Vac to 418 Vac
400 Vac for operation from 340 Vac to 440 Vac
415 Vac for operation from 353 Vac to 457 Vac
480 Vac for operation from 408 Vac to 528 Vac
Operating Input Frequency
Range 5 Hz
Operating Input Current See Appendix A, Table G through Table I.
Reduced for Generator
Adjustable
Input Current Harmonic
Content 5% THD at full load
Power Factor Minimum 0.99
Line Surges 6 kV OC, 3 kA SC per ANSI 62.41 and IEC 801‐4
Battery Voltage 384 Vdc (208V/220V units only)
432 Vdc
480 Vdc
