Using the Command Line Interface (CLI)
Access Point network objects are associated with Groups. The network objects are listed below and associated
parameters are described in the following Parameter Tables:
•
System Parameters - Access Point system information
– Inventory Management Information - Hardware, firmware, and software version information
• Network Parameters - IP and Network Settings
– IP Configuration Parameters - Configure the Access Point’s IP settings
— DNS Client for RADIUS Name Resolution - Configure the Access Point as a DNS client
– DHCP Server Parameters - Enable or disable dynamic host configuration
– Link Integrity Parameters - Monitor link status
• Interface Parameters - Configure Wireless and Ethernet settings
– Wireless Interface Parameters
— Wireless Distribution System (WDS) Parameters - Configure the WDS partnerships
– Wireless Interface SSID/VLAN/Profile Parameters - Configure the SSID and VLAN pairs and the security and
RADIUS profiles for each pair. Up to 16 pairs can be configured per wireless interface.
– Wireless Distribution System (WDS) Security Table Parameters
– Ethernet Interface Parameters - Set the speed and duplex of the Ethernet port
• Management Parameters - Control access to the AP’s management interfaces
– SNMP Parameters - Set read and read/write passwords
– HTTP (web browser) Parameters - Set up the graphical web browser interface. If required, enable SSL and
configure the SSL certificate passphrase.
– Telnet Parameters - Telnet Port setup
– Serial Port Parameters - Serial Port setup
– RADIUS Based Management Access Parameters - Configure RADIUS Based Management Access for HTTP
and Telnet access.
– SSH Parameters - Enable SSH and configure the host key.
– TFTP Server Parameters - Set up for file transfers; specify IP Address, file name, and file type
– IP Access Table Parameters - Configure range of IP addresses that can access the AP
– Auto Configuration Parameters - Configure the Auto Configuration feature which allows an AP to be
automatically configured by downloading a configuration file from a TFTP server during boot up.
• Filtering Parameters
– Ethernet Protocol Filtering Parameters - Control network traffic based on protocol type
– Static MAC Address Filter Table - Enable and disable specific addresses
– Proxy ARP Parameters - Enable or disable proxy ARP for wireless clients
– IP ARP Filtering Parameters - Control which ARP messages are sent to wireless clients based on IP settings
– Broadcast Filtering Table - Control the type of broadcast packets forwarded to the wireless network
– TCP/UDP Port Filtering - Filter IP packets based on TCP/UDP port
• Alarms Parameters
– SNMP Table Host Table Parameters - Enter the list of IP addresses that will receive alarms from the AP
– Syslog Parameters - Configure the AP to send Syslog information to network servers
• Bridge Parameters
– Spanning Tree Parameters - Used to help prevent network loops
– Storm Threshold Parameters - Set threshold for number of broadcast packets
– Intra BSS Subscriber Blocking - Enable or disable peer to peer traffic on the same AP
– Packet Forwarding Parameters - Redirect traffic from wireless clients to a specified MAC address
• RADIUS Parameters
– Set RADIUS Parameters - Configure RADIUS Servers and assign them to VLANs.
• Security Parameters - Access Point security settings
– MAC Access Control Parameter - Control wireless access based on MAC address
– Rogue Access Point Detection (RAD) Parameters - Enable and configure Rogue Access Point Detection.
– Hardware Configuration Reset - Disable or enable hardware configuration reset and configure a configuration
reset password.
