Installation

Mounting of Switch on Chassis

Centillion 1200N ATM Switch User Manual

7-9

NTP 297-8103-903

Mounting of Switch on Chassis

This section explains how to mount the ATM Switch on the chassis.

The ATM Switch chassis is optional. Refer to the preceding section on “Installation
Environmental Conditions” for the space necessary for chassis installation.

Recommended
Chassis

Figure 7-7: Recommended Chassis

From the left:

■

E176 JEB SPL Chassis (depth: 23.7 in. / 600 mm)

■

E178 JEB SPL Chassis (depth: 31.5 in. / 800 mm)

■

E116 JEB SPL Chassis (depth: 23.7 in. / 600 mm)

■

E118 JEB SPL Chassis (depth: 31.5 in. / 800 mm)
