Panasonic EVQWH - Manual

Multi Function Switches/EVQWH
Design and specifi cations are each subject to change without notice. Ask factory for the current technical specifi cations before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
– ES64 –
E
1
V
2
Q
3
W
4
H
5 6 7 8 9
Product Code Type Design No.
0.4max.
1.0
± 0.3
0.0
+0.1
0
(0.15)
1.6
1.0
3.9
6.1
8.3
5.95 7.95
2.05
± 0.2
6.1
± 0.2
7.1
± 0.3
2-1.4
±
0.2
6.5
±
0.2
7.1
±
0.2
0.3
±
0.3
2-0
+0.1
0
5.0
± 0.2
3.9
± 0.2
(2.25)
6-0.6
± 0.2
२2.5
–0.1
C0.2
6-0.3
±
0.2
0
Prohibited area for
circuit pattern foil
(Height
o
f
b
ent
p
art
o
f
cover)
than 0.1mm.
to all terminals have to be less
Distance from mounting surface
Mounting surface
Leaning
direction
Shaft pivot
(Opposite side of
leaning direction)
(Reference)
Date code
PWB land pattern for reference
No. 1
EVQWHE
Without boss
Micro Stick Switches
Type: EVQWH
■
Dimensions in mm (not to scale)
Electrical Rating 20 mA 15 Vdc
Mechanical
Operating force
Push 2.7 N±1.0 N
Leaning 1.4 N±0.8 N ✽ Note1
Travel 0.15 mm +0.2 mm
Leaning operation angle 5 °±2 °
Endurance Operating life 300000 cycles min.
Temperature range –20 °C to +70 °C
Minimum Quantity/Packing Unit 1200 pcs. Embossed Taping (Reel Pack)
Quantity / Carton 6000 pcs.
✽ Note1 : Leaning operation is that attach switch with φ8 knob and push edge of knob from upper side.
■
Specifi cations
■
Explanation of Part Numbers
■
Features
●
External dimensions: 6.1 mm ҂6.5 mm, height 2.05 mm
●
High operability: Tactile feedback ensured in all
fi ve operating directions
●
Ready for embossed taping and refl ow soldering.
–0.1
■
Rec om mend ed Applications
●
Operation switches for menu scrolling and confi rmation
for portable electronic equipment
(Mobile phones, Digital cameras, and PDAs)
Sep. 2010 00
