Transistors
1 Publication date: February 2003 SJC00009BED
2SA1022
Silicon PNP epitaxial planar type
For high-frequency amplification
Complementary to 2SC2295
■ Features
• High frequency voltage f
T
• Mini type package, allowing downsizing of the equipment and
automatic insertion through the tape packing and the magazine
packing
■ Absolute Maximum Ratings T
a
= 25°C
Parameter Symbol Rating Unit
Collector-base voltage (Emitter open) V
CBO
−30 V
Collector-emitter voltage (Base open) V
CEO
−20
V
Emitter-base voltage (Collector open) V
EBO
−5
V
Collector current I
C
−30
mA
Collector power dissipation P
C
200 mW
Junction temperature T
j
150
°C
Storage temperature T
stg
−55 to +150 °C
Parameter Symbol Conditions Min Typ Max Unit
Base-emitter voltage V
BE
V
CE
= −10 V, I
C
= −1 mA − 0.7 V
Collector-base cutoff current (Emitter open) I
CBO
V
CB
= −10 V, I
E
= 0 − 0.1 µA
Collector-emitter cutoff current (Base open) I
CEO
V
CE
= −20 V, I
B
= 0 −100 µA
Emitter-base cutoff current (Collector open) I
EBO
V
EB
= −5 V, I
C
= 0 −10 µA
Forward current transfer ratio * h
FE
V
CE
= −10 V, I
C
= −1 mA
70 220

Collector-emitter saturation voltage V
CE(sat)
I
C
= −10 mA, I
B
= −1 mA − 0.1
V
Transition frequency f
T
V
CB
= −10 V, I
E
= 1 mA, f = 200 MHz
150 300 MHz
Noise figure NF V
CB
= −10 V, I
E
= 1 mA, f = 5 MHz
2.8 dB
Reverse transfer impedance Z
rb
V
CB
= −10 V, I
E
= 1 mA, f = 2 MHz 22 Ω
Reverse transfer capacitance C
re
V
CE
= −10 V, I
C
= −1 mA, f = 10.7 MHz
1.2 pF
(Common emitter)
■ Electrical Characteristics T
a
= 25°C ± 3°C
0.40 +0.10
–0.05
(0.65)
1.50
+0.25 –0.05
2.8
+0.2 –0.3
2 1
3
(0.95) (0.95)
1.9 ±0.1
2.90 +0.20
–0.05
0.16 +0.10
–0.06
0.4
± 0.2
5˚
10˚
0 to 0.1
1.1
+0.2 –0.1
1.1
+0.3 –0.1
Rank B C
h
FE
70 to 140 110 to 220
Unit: mm
1: Base
2: Emitter
3: Collector
EIAJ: SC-59
Mini3-G1 Package
Marking Symbol: E
Note) 1. Measuring methods are based on JAPANESE INDUSTRIAL STANDARD JIS C 7030 measuring methods for transistors.
2. *: Rank classification
This product complies with the RoHS Directive (EU 2002/95/EC).
