Transistors
1 Publication date: August 2003 SJC00300AED
2SA1806J
Silicon PNP epitaxial planar type
For high speed switching
■ Features
• High speed switching
• Low collector-emitter saturation voltage V
CE(sat)
• SS-Mini type package, allowing downsizing of the equipment and
automatic insertion through the tape packing
■ Absolute Maximum Ratings T
a
= 25°C
Parameter Symbol Rating Unit
Collector-base voltage (Emitter open) V
CBO
−15 V
Collector-emitter voltage (Base open) V
CEO
−15 V
Emitter-base voltage (Collector open) V
EBO
−4
V
Collector current I
C
−50
mA
Peak collector current I
CP
−100
mA
Collector power dissipation P
C
125 mW
Junction temperature T
j
125
°C
Storage temperature T
stg
−55 to +125 °C
Parameter Symbol Conditions Min Typ Max Unit
Collector-base cutoff current (Emitter open) I
CBO
V
CB
= −8 V, I
E
= 0 − 0.1 µA
Emitter-base cutoff current (Collector open) I
EBO
V
CE
= −3 V, I
C
= 0 − 0.1 µA
Forward current transfer ratio h
FE1
* V
CE
= −1 V, I
C
= −10 mA
50 150

h
FE2
V
CE
= −1 V, I
C
= −1 mA
30
Collector-emitter saturation voltage V
CE(sat)
I
C
= −10 mA, I
B
= −1 mA − 0.1 − 0.2
V
Transition frequency f
T
V
CB
= −10 V, I
E
= 10 mA, f = 200 MHz 800 1 500 MHz
Collector output capacitance C
ob
V
CB
=
−5 V, I
E
= 0, f = 1 MHz 1 pF
(Common base, input open circuited)
Turn-on time t
on
Refer to the switching time 12 ns
Turn-off time t
off
measurement circuit 20 ns
Storage time t
stg
19 ns
■ Electrical Characteristics T
a
= 25°C ± 3°C
Unit: mm
Note) 1. Measuring methods are based on JAPANESE INDUSTRIAL STANDARD JIS C 7030 measuring methods for transistors.
2. *: Rank classification
0.27 ±0.02
3
1 2
0.12 +0.03
–0.01
0.80
± 0.05
(0.80)
0.85 1.60
± 0.05
0 to 0.02
0.10 max.
0.70
+0.05 –0.03
(0.375)
5˚
5˚
1.60 +0.05
–0.03
1.00 ±0.05
(0.50)(0.50)
+0.05 –0.03
Marking Symbol: AK
1: Base
2: Emitter
3: Collector
EIAJ: SC-89
SSMini3-F1 Package
Ranking is not given for any product.
Rank Q R
h
FE1
50 to 120 90 to 150
This product complies with the RoHS Directive (EU 2002/95/EC).
