COMMUNICATOR REPORTING CODES
✦ The 4 by 2 two-digit communicator reporting
code for each event has a factory set value.
These values may be customized to fi t
the specifi c installation and the reporting
requirements of the Central Station monitoring
the system.
✦ If Point ID reporting is enabled (the factory
default setting), each sensor can report a unique
alarm and trouble code.
✦ If Point ID is disabled, the “general” reporting
codes for each event type will be used.
✦ Each programming function is performed with
similar keystrokes. After the system is in Setup
Mode, enter the programming step number and
press HOME, then enter the new value and press
AWAY. For reference, follow the fi gures next to the
programming steps.
✴ If the new value is accepted, a “Bing” will sound. If the
new value is not accepted, a “Double Buzz” will sound.
✦ Making a value 0 causes the event not to
communicate to the Central Station.
✎ NOTE: The reporting codes are fi xed for opening
and closing. A unique code is reserved for the
master and the fi ve restricted user codes. See the
Opening & Closing Reporting Codes Table.
GENERAL REPORTING CODES
✦ Use program Steps #201 - 206 to change the
communicator reporting codes when Point ID is
disabled.
✦ Refer to the General Reporting Codes table to
view/edit the reporting codes for each of the fi ve
events. The factory settings are listed, along with a
blank area to write in the new installation values.
STEPS #201-206
Any value from 0-99 can be programmed for
each event using these steps (enter “0” to stop
an event from reporting).
✎ NOTE: Be careful not to duplicate codes unless the
Central Station requires specifi c codes for certain
types of events.
ENTERS PROGRAM STEP
NUMBER TO MODIFY
STORES NEW VALUE
PROGRAMMING
STEPS #201 - 206
ENTERS STEP NUMBER
0 - 99 FOR GENERAL
ALARM REPORTING CODE
STORES VALUE - 1 BING
General Reporting Codes Table
GENERAL REPORTING CODES
STEP #
PROGRAMMING FUNCTION
POSSIBLE 4 BY 2 VALUES
FACTORY 4 BY 2 VALUES
INSTALLATION 4 BY 2 VALUE
201
GENERAL FIRE REPORT CODE
0 - 99
1
202
GENERAL EMERGENCY REPORT CODE
0 - 99
2
203
GENERAL SILENT PANIC REPORT CODE
0 - 99
3
204
GENERAL BURGLARY REPORT CODE
0 - 99
4
206
GENERAL TROUBLE REPORT CODE
0 - 99
6
ADEMCO REPORTING CODES
EVENT
ALARM CODE
EXTENDED CODE
SENSOR EMERGENCY
E120
C0xx
CONSOLE EMERGENCY
E120
C026
SENSOR FIRE
E111
C0xx
CONSOLE FIRE
E110
C025
BURGLARY ALARM
E130
C0xx
SILENT PANIC
E122
C0xx
FORCE ARM
E574
C000
DURESS
E121
C000
CANCEL
E406
C000
SENSOR LOW BATTERY
E384
C0xx
SENSOR STATUS TROUBLE
E381
C0xx
CONSOLE LOW BATTERY
E302
C000
CONSOLE BATTERY RESTORE
R302
C000
2-WAY AUDIO
E606
C000
xx = SENSOR NUMBER IN EXTENDED REPORT
