Chapter 4
Hardware Installation
53
1. Working from the back, connect the power cord(s).
shows the 8-port switch power connector.
shows the 16-port switch power connector.
shows the power connections for two or four switches.
Allow the power cord to dangle temporarily.
FIGURE 4-9
The 8-Port Switch Power Connector
FIGURE 4-10
The 16-Port Switch Power Connector
Power
GBIC
Port 1
Port 8
Port 2
Port 4
Port 6
Port 3
Port 5
Port 7
microsystems
Power
Port 1
Port 3
Port 5
Port 7
Port 9
Port 11
Port 13
Port 15
Port 2
Port 4
Port 6
Port 8
Port 10
Port 12
Port 14
Port 16
GBIC
