DAB1 DISTRIBUTED AUDIO SYSTEM

Specifications

(continued)

:

Audio Connections

Source Inputs:

4 x Stereo RCA connectors

Source Loop Outputs:

4 x Stereo RCA connectors

Zone Line Outputs:

6 x Stereo RCA connectors

Speaker Outputs:

6 x Removable 4-pin screw connectors

Paging Connections:

1 x Mono RCA (input); 1 x Mono RCA (output)

Control Connections

Keypad Connections:

6 x RJ45 connectors(TIA568B Wiring)

IR Outputs (Mono 3.5mm connectors):

6 x Zone-specific; 4 x Common; 4 x Programmable1 x IR Link

Serial Control:

RS-232 connector

Serial Protocol (Inbound):

19.2K Baud, 8NI (fixed)

Serial Protocol (Outbound):

Adjustable

Sync Connections:

2 x Mono 3.5mm connectors

12V Control Input/Output:

Screw-to-Connect (14AWG compatible)

Computer Connection (For Programming):

1 x USB

Infrared

IR Receiver Bandwidth:

30kHz – 100kHz (Front-panel & keypad)

IR Receiver Range:

<30 feet

General

Power Requirements:

120VAC, 60Hz

Power Consumption:

960 Watts (Max power, 12 channels driven)

AC Convenience Outlets:

2 switched outlets

Zones 4 – 6 Keypad External Power:

12VDC, 1A (defeatable)

Dimensions (W x H x D):

16¾" x 6" x 15" (425mm x 152mm x 381mm)

Rack Space Requirements:

3U

Weight:

33 lbs (15kg)
