11. The function at the top of the IR Library’s new F UNCTION List will automatically be selected. If you want to learn a
different function you can use the mouse to select it.
12. Press and hold the button on the remote control that matches the function selected in Step 11 The IR Learner’s S IGNAL
LED will flash RED. Release the button when the the highlighted function on the Function List changes to the one below
the one you’re learning.
• Once an IR code is learned for a function a red dot appears to the left of the function name on the list.
13. Repeat Steps 11 & 12 until all desired functions are captured.
W AVEFORM V IEW T AB
The IR Library’s W AVEFORM V IEW tab ( Figure 55)
displays the IR waveform of any IR code in an IR
library.
• You cannot edit IR codes in this mode.
H
EX
V
IEW
T
AB
The IR Library’s H
EX
V
IEW
tab ( Figure 56)
displays the Hex Code data for any IR code in
the library.
If you have access to an IR code’s Hex Data you
can add the code to the U
SER IR Library even if
you don’t have it’s original remote control to
learn from:
1. Create a new remote and populate it with IR
command names (see Adding IR Codes to the
User Library, on page 39).
2. Click on the IR L IBRARY window’s H EX V IEW tab.
3. Select the name or one of the commands for
the new remote and copy its Hex Data into
the H
EX C ODE window.
4. Click the A PPLY button to save the Hex Code.
5. Repeat Steps 3 – 4 for all of the new IR codes you want to create.
I n t e r n a l C o m m a n d s
You can program DAB1 internal actions into macros using the Internal Commands command type ( Figure 57, on page 42).
The different available Internal Command functions are V OLUME , S OURCE , T UNER C ONTROL , M UTE , P OWER OFF, B ASS , T REBLE ,
B ALANCE , P AGING V OLUME and L OCK Z ONE . Each function has its own set of parameters that you set before using the function
in a macro:
FFuunnccttiioonn:: Selects which DAB1 function is to be configured.
Figure 55: IR Library W AVEFORM V IEW Tab and Window
H EX V IEW Tab Hex Code Window A PPLY Button
Figure 56: IR Library H EX V IEW Tab and H EX C ODE Window
