DAB1 DISTRIBUTED AUDIO SYSTEM

Keypad Connections

1. In direct runs from keypad to

controller, pull a length of CAT5
wire from every keypad mount-
ing location to the DAB1
location. The maximum length of
any single CAT5 cable is 1000’.

2. Terminate each CAT5 cable with

RJ45 connectors on each end.
Follow the TIA 568B wiring
standard (see

Figure 26).

3. We strongly recommend testing your connections with an RJ45 network cable tester to check for cable continuity,

miswiring, open connections, shorted connections or cross-pinning.

4. Connect the CAT5/RJ45 cable to the RJ45 Connection Jack on the back of the Keypad and to the zone’s Keypad

Controller Port on the DAB1 (see

Figure 27).

External Keypad Power

(see Figure 28)

The DAB1 supplies 1A of total keypad current through its keypad connections.
When the rear-panel Z

ONE

4 – 6 K

EYPAD

P

OWER

switch (see

Figure 28) is in the INT

(internal) position this current is evenly divided between all six Zone Keypad Connections.
When the switch is in the EXT (external) position, the DAB1 supplies all 1A of current to
Zones 1 – 3, while Zones 4 – 6 must be powered by an external PS2 power supply
(available separately) connected to the Z

ONE

4 – 6 K

EYPAD

E

XTERNAL

P

OWER

Connection.

The table below shows how many of each type of keypad can be used with internal keypad
power, and with a PS2 connected to the K

EYPAD

E

XTERNAL

P

OWER

Connection:

See page 49 for additional information about connecting K1 and K2 programmable keypads.

F1AL 12VDC

RS-232

12 VDC

1.0 A IN

ZONE 4-6

KEYPAD POWER

INT

EXT

+

F1AL 12VDC

12 VDC

1.0 A IN

ZONE 4-6

KEYPAD POWER

INT

EXT

+

Figure 28:

Keypad External Power

Connection

RJ45 Connector

(Flat Side UP)

TIA 568B

Wiring Standard

PIN

1

2

3

4

5

6

7

8

COLOR

White/Orange

Orange

White/Green

Blue

White/Blue

Green

White/Brown

Brown

SIGNAL

No Signal

No Signal

No Signal

IR Data

Status

No Signal

Ground

+12V DC

Figure 26:

Keypad Connection RJ45 Pinout

Z

O

N

E

1

Z

O

N

E

2

Figure 27:DAB1 Keypad

Controller Ports

Z

ONE

4 – 6 K

EYPAD

I

NTERNAL

P

OWER

Switch Position

INT (Internal)

Supplies 1A Total

Up to

6 Sets

Up to

12 Sets

Up to

12

Up to

24

Up to

6

Up to

12

Up to

3

Up to

7

EXT (External, w/PS2

Power Supply)

Supplies 2A Total

C4630 SE

Main/Numeric Keypads

Max LED Brightness,

(Each Set Draws 165mA)

K1 Keypads

Backlight ON,

(Each Draws

70mA)

Up to

12

Up to

24

DAB1 Keypads

Max LED

Brightness,

(Each Draws

52mA)

K2 Keypads

Med LED

Brightness,

(Each Draws

150mA)

K2 Keypads

Max LED

Brightness,

(Each Draws

265mA)
