Page 26
26
DAB1 DISTRIBUTED AUDIO SYSTEM
DAB1 Front Panel Controls and Indicators
(see
Figure 30)
1
1 .. U
U SS BB PP oo rr tt :: Connects the DAB1 to a USB-capable computer for programming via the Sonance Control Manager software.
2
2 .. TT uu nn ee rr PP rr ee ss ee tt BB uu tt tt oo nn ss :: Tunes the DAB1’s internal FM/AM tuner to any of 12 previously-programmed FM or AM stations.
3
3.. TT uu nn ee rr U
U PP // D
D O
O W
W N
N BB uu tt tt oo nn ss :: Tunes the DAB1’s internal FM/AM tuner to the next higher or next lower receivable radio
station.
4
4 .. FF M
M // A
A M
M SS ee ll ee cc tt oo rr BB uu tt tt oo nn :: Switches the DAB1’s internal tuner between FM and AM reception.
5
5.. SS yy ss tt ee m
m SS tt aa tt uu ss // TT uu nn ee rr D
D ii ss pp ll aa yy :: Displays the following information: System ON/OFF Status, Zone Being Controlled,
Zone ON/OFF status, Zone Source Selection, current radio station, status of Zone Volume, Mute, Treble, Bass,
Balance and Paging Volume.
6
6.. A
A
C
C TT II V
V EE
LLEED
D:: Illuminates green whenever any zone run by the DAB1 is ON.
7
7 .. A
A C
C O
O N
N LL EE D
D :: Illuminates red as long as the DAB1’s power cord is plugged-into a live outlet.
8
8.. II RR RR ee cc ee ii vv ee rr :: Allows direct control of the DAB1 by the included IR remote control. The IR Receiver also passes IR
commands from the DAB1 IR remote control (and when the rear-panel IR P
ASS
-T
HROUGH
switch is ON, IR commands from
3rd-party remotes) through to the rear-panel C
OMMON
IR outputs.
9
9.. ZZ oo nn ee FF uu nn cc tt ii oo nn V
V aa ll uu ee BB uu tt tt oo nn ss :: Operates in tandem with the Zone Function Select Button (#10). Modifies the follow-
ing parameters in the Zone being controlled: Volume Offset, Treble, Bass, Balance and Paging Volume. Mutes/Un-mutes
the Zone when the center of the double button is pressed.
1
10
0.. ZZ oo nn ee FF uu nn cc tt ii oo nn SS ee ll ee cc tt BB uu tt tt oo nn :: Selects between Volume, Treble, Bass, Balance and Paging Volume for the Zone being
controlled. When the button is pressed and held for 10 seconds the display shows the Firmware version installed. Press
the Z
ONE
P
OWER
Button (#11) to return to the menu.
• To lock-in changes made to a Zone’s the Volume Offset, Treble, Bass, Balance and Paging Volume:
a) Hold-down the Zone Function Select button for 15 seconds
16
7
210
13
34
8
12
511
9
Figure 30:
DAB1 Front-Panel
