DAB1 DISTRIBUTED AUDIO SYSTEM
E DITING IR C OMMANDS IN THE U SER IR L IBRARY
The commands in the U SER IR library will almost always
work without editing. However, to get some commands
to work you may need to rename a particular function or
change its IR carrier frequency, the number of times it is
repeated or its sustain characteristic. You can do this in
the IR Library Manager window.
To edit an IR command for a particular remote:
1. Click on that remote in the left-hand window of the
IR L IBRARY M ANAGER screen.
2. Click on the E DIT tab. The remote’s functions will
appear in the main part of the screen (see Figure 51).
You can change the remote function’s name (not its IR code), its IR frequency, the number of times it is repeated each time a
button is pressed and whether it is to be repeated while the button is held-down (commands in macros are not repeated). Click
on the parameter you want to change to highlight it and type-in the new value (for R
EPEAT , check or un-check the box).
NOT E : Ty p i c a l ly t h e re s h o u l d b e n o re a s o n t o c h a n ge a n y o f t h e s e p a ra m e t e r s . A c o m p o n e n t m ay n o t
re s p o n d t o a n I R c o d e i f y o u a l t e r a n y o f t h e s e p a ra m e t e r s t o i n c o r re c t v a l u e s .
A DDING IR C ODES TO THE U SER IR L IBRARY WITH THE O PTI L IN Q ® IR L EARNER
On occasion, there may be a particular component or command that is not in the U SER IR library. You can add IR
commands to the U SER IR Library by learning the command using the Sonance OptiLinQ ® IR Learner (part #92071,
available separately).
1. Open Sonance Control Manager and open the L
IBRARY menu. Select IR L IBRARY M ANAGER . The IR L IBRARY M ANAGER window
( Figure 49, opposite) will open.
2. Open the U SER . CML command library. If the U SER . CML library does not appear in the window you will have to navigate to it:
a) Open the F ILE menu and select O PEN . A browser window will appear.
b) Navigate to the S ONANCE C ONTROL M ANAGER program folder. (The default location for the IR
library folder is: C: > Program Files > Sonance > Sonance Control Manager > Command
Libraries.) Double-click the folder to open it.
c) Double-click the C OMMAND L IBRARIES folder. The M ASTER . CML and U SER . CML libraries will
appear in the window. Select U
SER
.
CML
and click O
PEN
. The U
SER
.
CML
library will now
appear in the IR L IBRARY M ANAGER window.
3. If you’re adding codes to a remote that’s already in the U SER . CML library, select it in the left-
hand window. If the remote isn’t in the U SER . CML library, create a new remote:
a) Open the R EMOTE menu and select N EW . The C REATE N EW R EMOTE screen ( Figure 52) will appear.
b) Use the drop-down boxes to enter the remote’s manufacturer, type and model. If the
manufacturer, type or model you need don’t appear in the drop-down menus you can type them in.
Figure 51:
IR Library Manager E DIT Tab
Edit Tab
Figure 52:
C REATE N EW R EMOTE
Screen
