48
DAB1 DISTRIBUTED AUDIO SYSTEM
S
IMULATE
B
UTTON
P
RESS
Serial Commands
No t e : R e q u i re s f i r m w a re v e r s i o n v 2 . 0 o r h i g h e r
The S IMULATE B UTTON P RESS serial command :P (see table on page 46) can be
used to allow a serial control device to trigger the macro that is programmed
into any keypad button in any DAB1 zone.
The command format is ::PPzzxxyyyyyy< >
P = Simulate button press
z = The Zone number of the command (1 – 6)
x = The command layer: 1 = P RESS , 2 = P RESS - AND -H OLD , 3 = D OUBLE -P RESS , 4 =
E XTRA C OMMANDS (see Expanded Control Features, on page 47)
yyy = The keypad button to be triggered, from the table to the right .
For example, to trigger the P RESS layer S OURCE 1 keypad button macro in
Zone 2 the serial command would be:
::PP2 21 11 17 7< >
P = S IMULATE B UTTON P RESS command
2 = Zone 2
1 = P RESS layer
17 = S OURCE 1 button
S i m u l a t e B u t t o n P r e s s C o m m a n d s i n M u l t i - U n i t S y s t e m s
As with other serial commands, a S IMULATE B UTTON P RESS command can be used
to control any DAB1 in a system with multiple units by adding the DAB1’s Unit
ID number (see page 30) to the command after the colon.
For example, to trigger the P
RESS layer S OURCE 1 keypad button macro in Zone
2 of Unit #3 in a multi-unit system, the serial command would be:
:: 3 3 PP 2 2 1 1 1 1 7 7 < < cc rr > >
3 = Unit ID #3
P = S IMULATE B UTTON P RESS command
2 = Zone 2
1 = P RESS layer
17 = S OURCE 1 button
Simulate Button Press
Serial Commands
BBuuttttoonn yyyyyy EEqquuiivvaalleenntt
1 1
2 2
3 3
4 4
5 5
6 6
7 7
8 8
9 9
10 (DAB KP) ; 10
0 (C4630 SE KP)
11 (DAB KP) ; 11
– (C4630 SE KP)
12 (DAB KP) ; 12
+ (C4630 SE KP)
Volume Up 13
Mute 14
Volume Down 15
Off 16
Source 1 17
Source 2 18
Source 3 19
Source 4 20
Pause 21
Play 22
Backward 23
Forward 24
Extra Commands* 001 – 200
* See page 50 for details about
Extra Commands.
