42
DAB1 DISTRIBUTED AUDIO SYSTEM
U Unniitt:: Assigns the DAB1 Internal Command to a particular DAB1 unit in
multi-unit systems.
ZZoonnee:: Assigns the DAB1 Internal Command to a particular zone. You
can assign commands to any zone being controlled by a particular
DAB1, or to all zones.
V
Vaalluuee:: Assigns an action to the Internal Command. Values vary
depending on which Function is selected.
Once you have configured the F
UNCTION , U NIT , Z ONE and V ALUE parame-
ters for the Internal Command, drag the icon into the M ACRO Window
to place it in a macro (see Figure 57).
S t a t u s T e s t
If you want a macro command to execute only if a certain condition
exists, add a Status Test command before the command in question. The
following conditions can be used to determine if a macro executes: This
Zone Is ON, This Zone Is Muted, Source 1 Is Selected, Source 2 Is
Selected, Source 3 Is Selected, Source 4 Is Selected, Any Zone Is ON,
Page Trigger Is Set.
To insert a Status Test command, select the desired condition and drag
the icon into the M
ACRO Window (see Figure 58).
T i m e D e l a y
Some audio/video components respond to IR
commands more quickly than others. Adding a
Time Delay after a macro command can give a
component additional time to process the
command and perform the required action
before the next IR command in the macro
sequence is sent. This can be especially useful
when sending commands to multi-disc CD and
DVD changers that can take several seconds to
retrieve and load a selected disc. Adding a Time
Delay command after a ‘disc select’ or ‘disc play’
command can help keep the system in sync.
To insert a Time Delay into a macro, select or
type the desired delay amount and drag the icon
into the M
ACRO Window (see Figure 59). You can
set a delay of 0.1 seconds up to 240 seconds.
Function
Parameters
Drag Icon
Into Macro
Window
Figure 57:
I NTERNAL C OMMAND Window
Select
Condition
Drag
Icon Into
Macro
Window
Figure 58:
S TATUS T EST Macro Window
Select
Delay
Time
Drag
Icon Into
Macro
Window
Figure 59:
T IME D ELAY Macro Window
