Sonance Cinema ® Series Home Theater Speakers
Features:
• Microtrim grille has only 0.20” of trim for a sleek,
modern appearance. Powerful neodymium magnet
attachment eases installation.
• Coaxial midrange/tweeter produces smoother
frequency response, improves stereo imaging and
reduces tonal variations caused by room acoustics.
• Dual and quad woofers minimize floor reflections,
improving performance by reducing the impact room
placement has on sound quality.
• Laminated carbon fiber/Rohacell ® woofer and midrange
cones are ver y light, stiff and non-resonant for improved
clarity and higher output.
• Die-cast aluminum woofer baskets reduce distortion by
maintaining precise voice coil alignment.
• Non-resonant, integrated ¾” high-gloss black MDF
enclosures promote natural, uncolored sound while
minimizing sound spillover into adjacent rooms.
• Viscoelastic enclosure damping material minimizes
vibration transfer from enclosure to wall for clearer
sound and reduced sound spillover into other rooms.
• Upgraded crossover components (including a double-
sided PCB) reduce power compression for higher output
with less distortion.
• Limited Lifetime Warranty — see Sonance Cinema Series
Instruction Manual for full warranty information.
Sonance Cinema Series Home Theater speakers combine
elegant, modern visual design with uncompromised in-wall
home theater per formance. New microtrim grilles have
only 0.20” of trim, giving these speakers a clean, sleek
appearance that seamlessly integrates into any designed
space. The grilles attach via power ful magnets, for simple,
quick installation.
All Sonance Cinema Series Home Theater speakers feature
coaxial midrange/tweeter drivers, with the tweeter mounted
precisely in the center of the shallow midrange cone.
This provides more consistent frequency response and
stereo imaging for listeners seated both on-axis and
of f-axis of the speaker.
Multiple woofers minimize frequency response variations
caused by floor reflections. This, along with the coaxial
midrange/tweeter driver, delivers exceptional musicality
and accuracy along with ver y low sensitivity to room
placement.
All Sonance Cinema Series Home Theater speakers feature
an integrated enclosure made from non-resonant ¾” high-
gloss black MDF and damped with a special viscoelastic
laminate. This helps produce dramatically lifelike sound
and reduce sound spillover into adjacent rooms.
Sonance Cinema Series Home Theater speakers are
available in front channel (LCR) and surround channel
(SUR) models. Both models are of fered in a dual-woofer
configuration as well as a quad-woofer configuration that
has the additional output required for the largest home
theaters.
B D
AC E
A = 8 7 /
8
” (225mm)
B = 21 7 /
8
” (556mm)
C = 3 7 /
8
” (98mm)
D = 20 ½” (521mm)
E = 7 ½” (191mm)
A = 8 7 /
8
” (225mm)
B = 34 7 /
8
” (886mm)
C = 3 7 /
8
” (98mm)
D = 33 ½” (851mm)
E = 7 ½” (191mm)
LCR1/SUR1
LCR2/SUR2
S ONANCE C INEMA S ERIES H OME T HEATER S PEAKERS
( LEFT TO RIGHT ) LCR2, SUR2, LCR1, SUR1
Dimensions:
