Symmetricom XL-GPS User Manual

Page 84

997-01530-01, Rev. C-25, Jan 2008

F100 – Network Port Configuration & XL-GPS Firmware

F100 provides two groups of commands:

•

Group 1, available through the keypad and the command line, provides access to network port
settings and hardware/Firmware status information.

•

Group 2, available through the command line only, provides commands for changing system
firmware, changing NTP & SNMP parameters, changing the user name/password, resetting the
unit, and pinging other network devices.

Warning

: The F100 commands have the capacity to remove the XL-GPS from the network and disable

the XL-GPS’s system firmware. Use judiciously.

Reboot Warning

: Saving changes to any F100 parameter using the keypad will reboot the XL-GPS.

Some of the F100 command line commands also reboot the XL-GPS. These are identified in the
following documentation.

Group 1

You can use both the keypad and the command line interface to access the following parameters:

•

Ethernet address:

XL-GPS contains a unique Ethernet or Media Access Control (MAC) address

comprised of a unique number assigned to the manufacturer, and a unique number assigned to
the unit. This is factory set and cannot be changed.

•

IP Address

: Sets a static Internet Protocol (IP) address for the unit.

•

Subnet Mask

: Sets a valid subnet-mask used in IP addressing. Subnetting allows for the more

efficient allocation of network addresses and management of network traffic.

•

Default Gateway

: The address of the router that handles packets addressed to IP devices outside

the local-area network.

•

10 100 BASE-T

: View network port setting: 10 or AUTO.

•

Remote Lockout

: Enables or disables remote access through the XL-GPS’s standard network

port. Enabling Remote Lockout limits users to the front-panel keypad or Serial I/O port.

•

Flash CRC

: Status - Passed or failed.

•

RAM

: Status - Passed or failed.

•

Serial

: Status - Passed or failed.

•

Version Test

: Status - Passed or failed
