46 997-01530-01, Rev. C-25, Jan 2008
S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S
1
F11 – Time Output Format
Use function F11 to review or change the format of the time output string used in F8 and F9. The as-
shipped factory setting for F11 format is null, which enables F8’s and F9’s default time output formats.
The default format for
F8 – Continuous Time Once-per-Second is:
DDD:HH:MM:SSQ
Note:
F8 does not display milliseconds, regardless of the format defined in F11.
The default format for F9 – Time On Request is:
DDD:HH:MM:SS.mmmQ
where:
The time quality character, “Q”, is one of the following characters:
See “F5 – Time-Quality Setup” on page 39 and “F13 – Time Error” on page 48 for more information.
When the unit responds to “F11” with the current format string (as shown in the following example),
the first character after the “F11” is a blank separator; it is not part of the format string.
= ASCII Start-of-Heading character.
= ASCII Carriage Return character.
= ASCII Line Feed character.
DDD
= Day-of-year.
HH
= Hours.
MM
= Minutes.
SS
= Seconds.
.
= ASCII decimal point.
mmm
= Milliseconds.
:
= Colon separator.
Q
= Time quality character table below.
SPACE
= Time error is less than time quality flag 1’s threshold
.
= Time error has exceeded time quality flag 1’s threshold
*
= Time error has exceeded time quality flag 2’s threshold
#
= Time error has exceeded time quality flag 3’s threshold
?
= Time error has exceeded time quality flag 4’s threshold
Or
A reference source is unavailable
