50 997-01530-01, Rev. C-25, Jan 2008
S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S
1
Keypad
When Position Mode is “LLA”, the position of the antenna is displayed in degrees, minutes, and seconds
using the following format:
<°>'"
where:
For example:
LATITUDE
N38°23’53.2”
or
LONGITUDE
W122°42’53.0”
Altitude Mode is available in Meters only.
Altitude is displayed in meters above (“+”) or below (“-”) the WGS 84 ellipsoid.
Command Line
Use the following format to display the current settings display the current position for the GPS receiver
in LLA coordinates:
F50LLA
XL-GPS responds with the coordinate information in the following format:
F50d'"d'"
>
= N or S for latitude; E or W for longitude; – for negative altitude and or + for positive altitude.
= two-digit degrees for latitude or three-digit degrees for longitude.
= two-digit minutes.
'
= ASCII character '
= two-digit seconds plus one-digit 10ths of seconds.
"
= ASCII character "
