5. Adjust potentiometer VR1 until the first print position is at the desired location on
the label. If the potentiometer does not have enough range, you will have to
change the Label Pitch setting using the PO command.
Note: The printer will return to the default settings specified by the PG
command when power is cycled.
6. Press the FEED key to stop the printing.
Note: Adjusting the Label Pitch with VR1 will affect the stop position of the label and
the cut/dispense/tear-off positions.
ABCDEFG
ABCDEFG
ABCDEFG
Original First
Line Print
Position
Must be moved
with Minus (-)
Offset to print
on leading
edge of label
Moved with
Positive (+) Offset
to print on trailing
edge of label
Label
Feed
Direc
ti
on
Leading Edge of Label as
detected by the sensor
S
ensor
Posi
ti
on
Section 2. Installation and Configuration
SATO CT Series Printers 9001069 A Page 2-17
