Font/Graphic Download (DS1-3). Enables the downloading of fonts and/or
graphics to printer memory.
Print Method (DSW4). Selects Direct Thermal or Thermal Transfer print mode for
a CT4XXTT printer.
Head Check (DSW5). When selected, the printer will check for head elements that
are electrically malfunctioning.
VR1 Potentiometer Function (DSW6). Select the function adjusted by VR1.
When placed in the Off position, VR1 will adjust the pitch offset value over a range of
+/- 3.75 mm. When placed in the On position, VR1 will adjust the print darkness
range.
Hex Dump (DSW7). When ON, the printer will print out the hex value for each
character received. When OFF, the printer will accept and process the data stream in
a normal fashion.
DSW1 DSW2 DSW3 SETTING
Off On On Enable
1 2 3 4 5 6 7 8
ON
OFF
Configuration Switch
DSW4 SETTING
Off Direct
On Transfer
1 2 3 4 5 6 7 8
ON
OFF
Configuration Switch
DSW5 SETTING
Off Disabled
On Enabled
1 2 3 4 5 6 7 8
ON
OFF
Configuration Switch
DSW6 SETTING
Off Pitch
On Darkness
1 2 3 4 5 6 7 8
ON
OFF
Configuration Switch
DSW7 SETTING
Off Normal
On Hex
1 2 3 4 5 6 7 8
ON
OFF
Configuration Switch
Section 2. Installation and Configuration
Page 2-14 9001069 A SATO CT Series Printers
