CODE 128 CHARACTER TABLE
The Code 128 Table lists 105 data values for the three subsets: A, B, and C. Each
subset column displays either a single column of data or a double column of data.
•
If the subset column displays a single column of data, that is the data to be
entered to produce the result.
•
If the subset column displays a double column of data, the first column con-
tains the desired output, and the second column contains the actual charac-
ters to be entered.
For example, look at value 99 in the table:
If you are currently using Subset A or Subset B, you can change to Subset C by
encoding “>C”.
VALUE SUBSET A SUBSET B SUBSET C
99 Subset C >C Subset C >C 99
100 Subset B >D FNC4 >D Subset B >D
101 FNC4 >E Subset A >E Subset A >E
102 FNC1 >F FNC1 >F FNC1 >F
Note: When Subset C is chosen, you must specify an even number of data
positions because of the interleaved encodation method.
Appendix B: Bar Code Specifications
Page B-22 900106 9A SATO Ct Series Printers
