Font Configuration (SOH + FG)
Upon Receipt of an SOH (hexadecimal 01) followed immediately by an FG
(hexadecimal 4647) causes the printer to return a 102 byte Font/Graphics Status
Word bounded by an STX-ETX pair that reports information on the stored font or
graphic.
Note: The printer must be in the Font/Graphic Download (See Section 2:
Configuration Switch) mode before a response will be received.
BYTE
NUMBER
VALUE
DESCRIPTION
1-2
ASCII
Font ID Number
3-4
00
H
01
H
Font
Graphic
5-36
ASCII
Font Name
37-48
ASCII
Font Style
49-52
ASCII
Font Point Size
53-54
Binary
Character Width in dots
54-60
Binary
Character Height in dots
57-60
Binary
Font Size
58-64
Binary
Font Registration Number
65-68
Binary
Font Data Top Address
69-72
Binary
Total Size
73-74
Binary
Vertical/Horizontal Writing Flag
75
Binary
Character Pitch, Fixed/Variable
76
Binary
Family Attribute
77
Binary
Character Set
78
Binary
Italic Attribute
79-80
Binary
Weight Attribute
81-82
Binary
Spread
83-84
Binary
Assent in dots
85-86
Binary
Registration Start Code
86-87
Binary
Registration End Code
88-95
Binary
Reserved
96-98
Binary
Code
99-100
Binary
Horizontal Valid Size
101-102
Binary
Left Gap Size
