2. USING THE DEVELOPER’S KIT
29
LZT 123 7263 R1C
2. Using the Developer’s Kit
This section provides you with the information needed to setup and use
the developer’s kit. Before changing switch and jumper settings, refer
to “2.3 Jumpers, Switches and Connectors”, page 32.
Front and rear views of the developer’s kit are shown below. To access
the inside, remove the 8 screws on the top of the box and the cover plate.
Figure 2.1 Front view
Figure 2.2 Rear view
GM47/GM48 Developer's Kit
HANDSET
DCIO
Vcc
12v
PCM
MIC EAR
NC
OFF
ON
+5V
OFF
APP
SE
RV
ICE
ST
AT
US
VIO ON/OFF
UART3
UART1
UART2
RF
