Network Management Card & Modbus/Jbus 34022321XT indice :AE Page 93/98
Network Management Teleservice Card
APC by Schneider Electric
www.apc.com
11.2 SNMP objects
11.2.1 MGE MIB
The NMC card implement reduce MGEUPS MIB, with the objects bellow managed.
Access to the MGE MIB is 1.3.6.1.4.1.705.1.
MIB object SNMP Format Add.path
upsmgIdentFamilyName String {1,1,0}
upsmgIdentModelName String {1,2,0}
upsmgIdentFirmwareVersion String {1,4,0}
upsmgIdentSerialNumber String {1,7,0}
upsmgConfigLowBatteryTime (Nota2) seconds {4,7,0}
upsmgConfigLowBatteryLevel (Nota2) % {4,8,0}
upsmgConfigAutoRestart (Nota2) 1(yes) 2(no) {4,9,0}
upsmgConfigVARating VA {4,12,0}
upsmgBatteryRemainingTime (Nota2) seconds {5,1,0}
upsmgBatteryLevel (Nota2) % {5,2,0}
upsmgBatteryVoltage (Nota2) deciVolts {5,5,0}
upsmgBatteryCurrent (Nota2) deciAmps {5,6,0}
upsmgBatteryTemperature (Nota2) °C {5,7,0}
upsmgBatteryFaultBattery (Nota2) 1(yes) 2(no) {5,9,0}
upsmgBatteryReplacement (Nota2) 1(yes) 2(no) {5,11,0}
upsmgBatteryLowBattery (Nota2) 1(yes) 2(no) {5,14,0}
upsmgBatteryChargerFault (Nota2) 1(yes) 2(no) {5,15,0}
upsmgBatteryLowCondition (Nota2) 1(yes) 2(no) {5,16,0}
upsmgInputPhaseNum (Nota2) {6,1,0}
mginputVoltage_1 (Nota2) DeciVolts {6,2,1,2,1,0}
mginputVoltage_2 (Nota2) DeciVolts {6,2,1,2,2,0}
mginputVoltage_3 (Nota2) DeciVolts {6,2,1,2,3,0}
mginputFrequency_1 (Nota2) DeciHz {6,2,1,3,1,0}
mginputFrequency_2 (Nota2) DeciHz {6,2,1,3,2,0}
mginputFrequency_3 (Nota2) DeciHz {6,2,1,3,3,0}
mginputCurrent_1 (Nota2) DeciAmps {6,2,1,6,1,0}
mginputCurrent_2 (Nota2) DeciAmps {6,2,1,6,2,0}
mginputCurrent_3 (Nota2) DeciAmps {6,2,1,6,3,0}
upsmgInputBadStatus (Nota2) 1(yes) 2(no) {6,3,0}
upsmgInputLineFailCause (Nota1) {6,4,0}
upsmgOutputPhaseNum {7,1,0}
mgoutputVoltage_1 deciVolts {7,2,1,2,1,0}
mgoutputVoltage_2 deciVolts {7,2,1,2,2,0}
mgoutputVoltage_3 deciVolts {7,2,1,2,3,0}
mgoutputFrequency_1 deciHz {7,2,1,3,1,0}
mgoutputFrequency_2 deciHz {7,2,1,3,2,0}
mgoutputFrequency_3 deciHz {7,2,1,3,3,0}
mgoutputLoadPerPhase_1 % {7,2,1,4,1,0}
mgoutputLoadPerPhase_2 % {7,2,1,4,2,0}
