10.3.2 Measurement table
Description of the physical quantity
Word (hex)
Unit
Data
type
I1 (I phase 1) mains 1 (Nota 1)
100
A
unsigned
I2 (I phase 2) mains 1 (Nota 1)
101
A
unsigned
I3 (I phase 3) mains 1 (Nota 1)
102
A
unsigned
I1 (I phase 1) mains 2 (Nota 2)
106
A
unsigned
I2 (I phase 2) mains 2 (Nota 2)
107
A
unsigned
I3 (I phase 3) mains 2 (Nota 2)
108
A
unsigned
I1 (I phase 1) output
109
A
unsigned
I2 (I phase 2) output
10A
A
unsigned
I3 (I phase 3) output
10B
A
unsigned
I battery (Nota 1)
10E
A
signed
U12 mains 1 (Nota 1)
115
V
unsigned
U23 mains 1 (Nota 1)
116
V
unsigned
U31 mains 1 (Nota1)
117
V
unsigned
U mains 2 (phase 1) (Nota 2)
11E
V
unsigned
U mains 2 (phase 2) (Nota 2)
11F
V
unsigned
U mains 2 (phase 3) (Nota 2)
120
V
unsigned
U12 mains 2 (Nota 2)
121
V
unsigned
U23 mains 2 (Nota 2)
122
V
unsigned
U31 mains 2 (Nota 2)
123
V
unsigned
U1N output
124
V
unsigned
U2N output
125
V
unsigned
U3N output
126
V
unsigned
U12 output
127
V
unsigned
U23 output
128
V
unsigned
U31 output
129
V
unsigned
U battery (Nota 1)
12D
V
unsigned
Output active power (phase 1)
130
kW
unsigned
Output active power (phase 2)
131
kW
unsigned
Output active power (phase 3)
132
kW
unsigned
Output apparent power (phase 1)
133
kVA
unsigned
Output apparent power (phase 2)
134
kVA
unsigned
Output apparent power (phase 3)
135
kVA
unsigned
Output total active power
136
kW
unsigned
Output total apparent power
137
kVA
unsigned
% output load level
139
%
unsigned
Peak factor phase 1 x 100
13A
-
unsigned
Peak factor phase 2 x 100
13B
-
unsigned
Peak factor phase 3 x 100
13C
-
unsigned
Power factor x 100
13D
-
unsigned
AC normal frequency (Nota 1)
13E
dHz
unsigned
AC bypass frequency
140
dHz
unsigned
Output frequency
141
dHz
unsigned
Battery backup time (Nota 1)
149
Min
unsigned
