Network Management Teleservice Card
APC by Schneider Electric
www.apc.com
Status description
Status to 0
Status to 1
Word
hex
Bit
0 - F
Status Familly
for
BMS design
AC bypass thermal overload (Nota 7)
No
yes
46
6
Minor Fault
AC Bypass out of tolerance (Nota 7)
No
yes
46
7
Major Warning
AC bypass frequency out of tolerance (Nota 7)
No
yes
46
9
Minor Warning
AC bypass voltage out of tolerance (Nota 7)
No
yes
46
A
Minor Warning
AC bypass switch (Q4S)
Open
Closed
46
E
Status
Static switch major fault (Nota 7)
absent
present
47
0
Minor Fault
Inverter desynchronized with AC bypass
absent
present
47
1
Status
Output switch (Q5N)
Open
Closed
47
B
Status
Charger major fault
No
Yes
49
0
Minor Fault
Battery charging (Nota 5)
No
Yes
49
3
Status
Inverter major fault (Nota 5)
No
Yes
4C
1
Minor Fault
Inverter overload (Nota 5)
No
Yes
4C
2
Major Warning
Inverter thermal overload (Nota 5)
No
Yes
4C
3
Minor Fault
Inverter limitation (Nota 5)
No
Yes
4C
4
Status
UPS fuse fault (Nota 5)
absent
Present
4C
5
Minor Fault
Load Short circuit
absent
Present
4F
1
Minor Fault
Nota 1 : for Battery charge it is necessary to set 2 bits, for legacy JBUS table
Nota 3 : switch status equal 1, when closed
Nota 4 :
INMC/NMTC
Galaxy
@41 Hex
@41 Bin
@41 Bit3
@41 Bit2
@41 Bit1
@41 Bit 1, 2 and 3 in Dec
Unitary
2
0010
0
0
1
1
Modular
4
0100
0
1
0
2
Parallel
6
0110
0
1
1
3
SSC
8
1000
1
0
0
4
Nota 5 : This Information is not present with a Static Switch Cabinet unit.
Nota 6 : Device Ventilation Fault is present only in a Static Switch Cabinet 800kVA, this information is not present in a Static Switch Cabinet
1200kVA
Nota 7 : For a configuration with UPS in parallel with SCC unit, the Main 2 data need to read on the card installed in the SSC unit.
Nota 8 : Available with NMC firmware 808 and UPS package AN
Nota 9 : Available with NMC fw 808 and G7000 package AM
