Network Management Card & Modbus/Jbus 34022321XT indice :AE Page 74/98
Network Management Teleservice Card
APC by Schneider Electric
www.apc.com
10.1.3.5 Choice 5: Return to Jbus Default Configuration
Returns to the Jbus default configuration (0x01, 9600, 8, 1, none)
Wait during Jbus configuration returns to default ...
Jbus Configuration has been set to default one.
10.1.3.6 Choice 6: Display Jbus frames
Enables the display of the Jbus frames:
Recv : 01 01 00 00 00 64 3d e1
Send : 01 81 02 c1 91
Recv : 01 03 00 62 00 64 e5 ff
Send : 01 03 c8 00 00 00 00 00 00 00 00 00 00 00 00 00 ...
Recv : 01 01 00 00 00 64 3d e1
Send : 01 81 02 c1 91
Recv : 01 03 00 62 00 64 e5 ff
Send : 01 03 c8 00 00 00 00 00 00 00 00 00 00 00 00 00 ...
