Network Management Card & Modbus/Jbus 34022321XT indice :AE Page 80/98
Network Management Teleservice Card
APC by Schneider Electric
www.apc.com
10.3.3.3 Sensor customisation table (RO)
Description
Word (hex) Bit
(0-15)
High threshold temperature (°C) 32C 0
Low threshold temperature (°C) 32D 0
Temperature hysteresis (°C) 32E 0
Offset temperature 32F 0
High threshold humidity (%) 330 0
Low threshold humidity (%) 331 0
Humidity hysteresis (%) 332 0
Humidity offset 333 0
Inputs call mask – input 1 close notification 334 0
Inputs call mask – input 2 close notification 334 2
Inputs call mask – low humidity notification 334 7
Inputs call mask – high humidity notification 334 6
Inputs call mask – input 1 open notification 334 1
Inputs call mask – input 2 open notification 334 3
Inputs call mask – low temperature notification 334 5
Inputs call mask – high temperature notification 334 4
Input 1 identification 336 0
Input 2 identification 33A 0
