Network Management Card & Modbus/Jbus 34022321XT indice :AE Page 79/98
Network Management Teleservice Card
APC by Schneider Electric
www.apc.com
Description of the physical quantity
Word (hex)
Unit
Data
type
Battery temperature (Nota 1)
14A
°C
unsigned
Battery charging level (Nota 1)
14B
%
unsigned
U AC normal (phase 1) (Nota 1)
150
V
unsigned
U AC normal (phase 2) (Nota 1)
151
V
unsigned
U AC normal (phase 3) (Nota 1)
152
V
unsigned
Number of battery block (Nota 1)
153
-
unsigned
Total battery capacity (Nota 1)
154
Ah
unsigned
Nominal Apparent Power
209
kVA
unsigned
Nominal battery voltage (Nota 1)
213
V
unsigned
Nota1 : This Information is not present in a Static Switch Cabinet.
Nota2 : For a configuration with UPS in parallel with SCC unit, the Main 2 data need to read on the card installed in the SSC unit.
10.3.3 Environnement Sensor Table
10.3.3.1 Sensor Status table
Status description
Status to 0
Status to 1
Word (hex)
Bit
0 - F
Communication fault
no
Yes
45
0
Alarm : temperature too high
no
Yes
45
1
Alarm : temperature too low
no
Yes
45
2
Alarm : humidity too high
no
Yes
45
3
Alarm : humidity too low
no
Yes
45
4
Input 1 alarm
no
Yes
45
5
Input 2 alarm
no
Yes
45
6
Input 1
open
Closed
48
0
Input 2
open
Closed
48
1
10.3.3.2 Sensor Measurements table
Description of the physical quantity
Word (hex)
Unit
Temperature measure
180
°C
Maximum temperature
181
°C
Minimum temperature (°C)
184
°C
Humidity measure (%)
187
%
Maximum humidity (%)
188
%
Minimum humidity (%)
18B
%
