Network Management Teleservice Card
APC by Schneider Electric
www.apc.com
Ethernet port
LED Colour Activity Description
ACT Green ◗ Off ◗ Card not connected to the network.
◗ On
◗ Card connected to the network but
without activity
◗ Flashing
◗ Port is active in receiving /
transmission
100M Orange ◗ Off ◗ Port operating at 10Mbits/s.
◗ On ◗ Port operating at 100Mbits/s.
Service port (Settings/Sensor)
LED Colour Activity Description
UPS Green ◗ Off ◗ Card startup in progress.
Data ◗ On ◗ Communication with UPS in progress
◗ Flashing
◗ Normal operation.
Communication with the UPS is
operational
RS232 Orange ◗ Off ◗ Configuration menu is active
◗ On ◗ Normal operation. Configuration
menu is deactived
◗ Flashing ◗ Communication with the Environment
Sensor (option).
3.3 Installation in the UPS
The Network Management Card (66123) can be "hot" installed in the MGE Galaxy 7000 UPS or SSC unit.
Note the card's MAC address prior to insertion
Connect the ETHERNET cable
Insert and tighten the card's retaining screws
Wait 3 min.; the card is completely operational when the green UPS Data LED flashes continuously
3.4 Sensor installation (option)
The Environment sensor is available as an option on the Network Management Card. SKU number is 66846.
The sensor allows remote monitoring of the UPS's environment through regular measurements: temperature, humidity, status of two external
contacts. It also enables notification of alarms (e-mail, trap SNMP) according to pre-programmed thresholds.
It is connected to the Service port (Settings/Sensor) directly on the Network Management Card with a standard Ethernet cable (20 meters
maximum).
Recognition is automatic. Supervision and configuration are performed via a menu that can be accessed directly from the home page.
