CHAPTER 6
Cabling E-Series Routers

6-14

Cabling I/O Modules

The following section illustrates the common connector types used with
E-series I/O modules. For information about the connectors on the
different line modules, see

Chapter 12, Module Specifications

BNC Connectors

Figure 6-7 I/O module with BNCs

CT3

I/O

Port 0

Port 1

g013755
