CT1 and CE1 I/O Modules
E-Series Routers
A-7
4
Port 1 TX TIP
29
Port 1 TX RING
5
Port 2 RX TIP
30
Port 2 RX RING
6
Port 2 TX TIP
31
Port 2 TX RING
7
Port 3 RX TIP
32
Port 3 RX RING
8
Port 3 TX TIP
33
Port 3 TX RING
9
Port 4 RX TIP
34
Port 4 RX RING
10
Port 4 TX TIP
35
Port 4 TX RING
11
Port 5 RX TIP
36
Port 5 RX RING
12
Port 5 TX TIP
37
Port 5 TX RING
13
Port 6 RX TIP
38
Port 6 RX RING
14
Port 6 TX TIP
39
Port 6 TX RING
15
Port 7 RX TIP
40
Port 7 RX RING
16
Port 7 TX TIP
41
Port 7 TX RING
17
Port 8 RX TIP
42
Port 8 RX RING
18
Port 8 TX TIP
43
Port 8 TX RING
19
Port 9 RX TIP
44
Port 9 RX RING
20
Port 9 TX TIP
45
Port 9 TX RING
21
n/c
a
46
n/c
22
n/c
47
n/c
23
n/c
48
n/c
24
n/c
49
n/c
25
n/c
50
n/c
a. n/c=no connect
Table A-7 Pinout of 50-pin Telco connector to ports 10–19
Pin
Signal
Pin
Signal
1
Port 10 RX TIP
26
Port 10 RX RING
2
Port 10 TX TIP
27
Port 10 TX RING
3
Port 11 RX TIP
28
Port 11 RX RING
4
Port 11 TX TIP
29
Port 11 TX RING
5
Port 12 RX TIP
30
Port 12 RX RING
6
Port 12 TX TIP
31
Port 12 TX RING
7
Port 13 RX TIP
32
Port 13 RX RING
8
Port 13 TX TIP
33
Port 13 TX RING
Table A-6 Pinout of 50-pin Telco connector to ports 0–9 (continued)
Pin
Signal
Pin
Signal
