Equipment Rack Requirements
E-Series Routers
3-7
Figure 3-2 Airflow for E-series routers
3- to 4-ft.
(0.9- to 1.2-m)
access space
Air intake
ERX-14xx model
Air intake ERX-310 router
and ERX-7xx model
Air output ERX-14xx model
via plenum
7-ft. (2.1-m) rack
Air output
ERX-310 router and
ERX-7xx model
g013741
