Upgrading NVS Cards on SRP Modules
E-Series Routers
9-5
Replacing an NVS Card
To replace an NVS card on an SRP module:
1
Obtain an antistatic container for the NVS card you will remove (see
Storing Modules and Components , earlier in this chapter).
2
With a small flathead screwdriver, remove the faceplate from the
NVS card slot on the SRP module (see
Figure 9-1 ).
3 Use the screwdriver to depress the button next to the NVS card (see
Figure 9-1 ).
This action releases the NVS card.
Figure 9-1 NVS card slot on SRP module
4
Remove the NVS card and place it in the antistatic container.
5
Insert the new NVS card into the slot.
6
Push the new NVS card as far as you can in the slot.
When you push the card far enough, it will click into place.
7 Replace the faceplate on the NVS card slot.
Faceplate
Release button
NVS card
g013763
