CHAPTER 5
Installing Modules 5-8
Installing an SRP I/O Module
To install an SRP I/O module:
1
Ground yourself by using an antistatic wrist strap or other device.
2
With a Phillips screwdriver, loosen the captive screws that secure the
blank faceplate covering the empty chassis slot, if present, and
remove the faceplate.
3 Remove the SRP I/O module from its antistatic bag.
4 Slide the module into the chassis by placing it between the guides of
the selected slot and pushing the module until it stops.
Note: See figures in Chapter 1, E-Series Overview , for module locations.
5 Tighten the module’s captive screws using a Phillips screwdriver.
Turn both screws several times before tightening them completely to
allow the module to sit correctly.
Installing an SRP Module
To install an SRP module:
1
Ground yourself by using an antistatic wrist strap or other device.
Note: See figures in Chapter 1, E-Series Overview , for module locations.
2 Choose the slot in which you want to install the module.
• ERX-14xx models – slot 6 or 7
• ERX-7xx models – slot 0 or 1
• ERX-310 router – slot 0
3
With a Phillips screwdriver, loosen the captive screws that secure the
blank faceplate covering the empty chassis slot, if present, and
remove the faceplate.
4 Remove the SRP module from its antistatic bag.
5 Verify that the ejectors are in the open position, as shown in
Figure 5-5 .
