5.8.1 (c) Combined cable (Ethernet, RS485 and power):
Number of twisted pairs 8
Maximum cable diameter 15 mm
Maximum cable length
100 meters
5.8.2 Recommended Cables
Ethernet: Cable, Cat 6 S-FTP 4x2xAWG24 JAI No. 2900.00.262
Power and RS485: Cable Twisted Pair 4x2x0.5mm2 JAI No. 2900.00.267
Combined cable Cat 6, RS485 and power: JAI No. 2900.00.268
5.8.3 Mounting the cables
Please refer to Section 3 on page 15 of this manual.
