5.2.4 (a) Ethernet Interface
Description: 100 Mb Ethernet interface. The signal must be connected to a gigabit Ethernet switch
for best performance. The cable must be a Cat 5e or preferably a Cat 6 cable. The wire color
marking on the PCB is standard Ethernet wire colors.
5.2.4 (b) Power input
Voltage 24VDC±20%
Current 0.3A with heaters and LED light off
Max current inrush app 2.5A
Heaters on 1.3A totally
5.2.5 Connector physical Interface
Figure 42. Physical interface table.
Pin Signal Description
Connection to
J-Panel X1
or X2
Remarks
1 Ethernet A+ Ethernet signal to gigabit switch pin 1 Cat5e/6 cable white/orange
2 Ethernet A- Ethernet signal to gigabit switch Pin 2 Cat5e/6 cable orange
3 Ethernet B+ Ethernet signal to gigabit switch Pin 3 Cat5e/6 cable white/green
4 Ethernet B- Ethernet signal to gigabit switch Pin 4 Cat5e/6 cable green
5 Ethernet C+ Ethernet signal to gigabit switch Pin 5
Cat5e/6 cable white/blue
not used with VIS CAM
6 Ethernet C- Ethernet signal to gigabit switch Pin 6
Cat5e/6 cable blue
not used with VIS CAM
7 Ethernet D+ Ethernet signal to gigabit switch Pin 7
Cat5e/6 cable white/brown
not used with VIS CAM
8 Ethernet D- Ethernet signal to gigabit switch Pin 8
Cat5e/6 cable brown
not used with VIS CAM
9 Gnd Power ground Pin 9 Black wire in Red/Black pair
10 +24V dc Supply voltage Pin 10 Red wire in Red/Black pair
11 Vinit + Balanced trigger pulse positive Pin 11 White wire in Brown/White pair
12 Vinit - Balance tripper pulse negative Pin 12 Brown wire in Brown/White pair
13 RS485D+ RS485 Data+ for Lane Controller Pin 13 White wire in Red/White pair
14 RS485D- RS485 Data- for Lane Controller Pin 14 Red wire in Red/White pair
15 RS485D= RS485 Data+ for Lane Controller Pin 15 White wire in Orange/White pair
16 RS485D- RS485 Data- for Lane Controller Pin 16 Orange wire in Orange/White pair
