Matsushita CF-19FHGAX - Manual (Page 88)

C 802 F1G1E103A062 CAPACITOR, 25V, 0.01µF 1
C 803, 804, 806 F1G1C104A042 CAPACITOR, 16V, 0.1µF 3
C 805 F1J0J106A016 CAPACITOR, 6.3V, 10µF 1
CN 800 K1MY04BA0104 CONNECTOR 1
CN 801 K1MY06BA0309 CONNECTOR 1
CN 802 K1MY40A00001 CONNECTOR 1
CN 803 K1MY08AA0158 CONNECTOR 1
CN 804, 807 K1KA02BA0014 CONNECTOR 2
CN 805 K1MY10AA0158 CONNECTOR 1
CN 806 K1MY10BA0309 CONNECTOR 1
F 800 S K5H202Z00005 FUSE, 2A, 32V 1
IC 800 C0EBE0000460 IC 1
IC 801 C1DB00001417 IC, FLAT PAD CONTROLLER 1
Q 800, 801 B1GKCFJN0004 TRANSISTOR 2
R 800 ERJ2GEJ273X RESISTOR, 1/16W, 27K Ω 1
R 801, 802 ERJ2GEJ822X RESISTOR, 1/16W, 8.2K Ω 2
R 803 ERJ2GEJ105X RESISTOR, 1/16W, 1M Ω 1
R 804, 805 ERJ2GEJ222X RESISTOR, 1/16W, 2.2K Ω 2
RA 800 D1H81034A024 RESISTOR ARRAY 1
SW 800, 801 K0ZZ00000618 SW 2
SW 802, 803 EVQPLDA15 SWITCH 2
X 800 H2D400400012 OSCILLATOR, 4MHz 1
SW PCB
CN 950 K1MY10AA0158 CONNECTOR 1
LD 951 B3ABB0000210 DIODE 1
SW 950, 951, 952, 953, 954,
955
EVQPLDA15 SWITCH 6
LED-LEFT PCB
CN 841 K1MY10AA0158 CONNECTOR 1
LD 841, 842, 843, 844, 845,
846
B3ABB0000210 DIODE 6
PR PCB
C 851, 852, 854 F1J1A1050021 CAPACITOR, 10V, 1µF 3
C 855, 856, 857 J0MAB0000146 INDUCTOR 3
CA 851, 852, 854, 857, 858,
859
J0HABC000004 CAPACITOR ARRAY 6
CN 850 K1KYA0A00018 CONNECTOR 1
CN 851 K1KAA0AA0244 CONNECTOR 1
L 850 J0MAB0000200 INDUCTOR 1
L 852, 853 J0JJC0000015 INDUCTOR 2
LED-RIGHT PCB
LD 781 B3AGB0000040 DIODE 1
LD 782 B3ADB0000065 DIODE 1
LD 783 B3ABB0000210 DIODE 1
CN 780 K1MY06AA0158 CONNECTOR 1
SD PCB
LD 880 B3ACB0000020 DIODE 1
C 880 F1G1H330A542 CAPACITOR, 50V, 33pF 1
C 881, 882, 884, 885, 886,
887
F1G1C104A042 CAPACITOR, 16V, 0.1µF 6
C 889, 890, 891, 892 F1H2A103A020 CAPACITOR, 100V, 0.01µF 4
C 893 F1L3D102A003 CAPACITOR, 2000V, 1000pF 1
CN 880 K1MY24BA0310 CONNECTOR 1
CN 881 K1NA09E00076 CONNECTOR 1
CN 882 K1KA08BA0014 CONNECTOR 1
R 880 D1H87504A024 RESISTOR ARRAY 1
R 882 ERJ2GEJ103X RESISTOR, 1/16W, 10K Ω 1
T 880, 881 G5BYC0000015 TRANCE 2
HSDPA PCB
C 600, 603 F1G1H1010005 CAPACITOR, 50V, 100pF 2
C 601, 602, 604, 608 F1J0J106A016 CAPACITOR, 6.3V, 10µF 4
C 609, 610 EEFUD0J151ER CAPACITOR, 6.3V, 150µF 2
C 613, 614, 615, 616 F1G1C104A042 CAPACITOR, 16V, 0.1µF 4
C 611, 612, 617, 620 F1G1C104A042 CAPACITOR, 16V, 0.1µF 4
