Replacement Parts List
CF-19FHGAXxM
NRP: Non Reusable Parts
PART NO.
DESCRIPTION
Q'TY
E1
DL31U1633AAA
PCB, MAIN
RTL
1
E2
DL32U1633AAA
PCB, AUDIO
RTL
1
E3
DL33U1633AAA
PCB, IO
RTL
1
E4
DL31U1634AAA
PCB, PAD
RTL
1
E5
DL32U1634AAA
PCB, SW
RTL
1
E6
DL33U1634AAA
PCB, LED-LEFT
RTL
1
E7
DL34U1634AAA
PCB, PR
RTL
1
E8
DL36U1634AAA
PCB, LED-RIGHT
RTL
1
E9
DL37U1634AAA
PCB, SD
RTL
1
E10
DL38U1634AAA
PCB, HSDPA
RTL
1
E11
DL39U1634AAA
PCB, POWERSW
RTL
1
E12
DL3UP1552AAA
PCB, EXT ANT UNIT
RTL
1
E13
DL31U1635AAA
PCB, BT
RTL
1
E14
DL3UP1566AAA
BAT FPC UNIT
1
E15
DL3U11553AAA
WWAN MAIN ANT
RTL
1
E16
DL3U21553AAA
WWAN AUX ANT
RTL
1
E17
DL3U31553AAA
LAN-MAIN BT ANT
RTL
1
E18
DL3U41553AAA
LAN AUX ANT
RTL
1
E19
DL3UP1605AAA
CF-19 TS PCB UNIT
RTL
1
E20
DFJS1060ZA
WWAN COAXIAL CABLE
1
E21
DFJS1117ZA
LCD CABLE TS
1
E22
S N0GB1J000019
INVERTER
1
E23
S N3CAYYY00030
HARD DISK
1
E24
N2AZZY000078
KEYBOARD VISTA, U.S.
1
E25
DFJS1120ZA
MODEM CABLE
1
E26
S N5HAZ0000014
MODEM
1
E27
N5ZZ00000128
DDR2-667 200PIN SO-DIMM, 1GB
1
E28
DFJS1059ZA
WLAN COAXIAL CABLE
1
E29
S N5HZC0000031
WIRELESS LAN MODULE
1
E30
D4CZY103A003
THERMISTOR
1
E31
DFJS1043ZA
POWER SW CABLE
1
E32
N2EABEC00006
TOUCHPAD
1
E33
BR-2330A/SF
LITHIUM COIN BATTERY
1
E34
DFJS1119ZA
LAN CABLE
1
E35
K1NB94B00001
EXPRESS PCMCIA COMBO SLOT
1
E36
DFWV08A0108
LCD UNIT ASS'Y
1
E36-1
DL3DW0186AAA
LCD ASS'Y
1
E36-1-1
A2CA00000056
LCD BACKLIGHT, CCFGL
1
E36-1-2
DFHM0290ZA
REFLECTION ANGLE
1
E36-1-3
DFHR3H12YA
LCD REFLECT TAPE
1
E36-2
DFHR3612ZA
LCD PWB SPACER
1
E36-3
DFHR3647YA
SPACER SHEET
2
E36-4
DFHR3D92YA
LCD BACK DAMPER
1
E36-5
DFHR3570YA
LCD BACK CUSHION
1
E36-6
DFHR3571YA
LCD BACK CUSHION S
2
E36-7
DXHM0042ZA
SCREW
2
E36-8
DFHR3648ZA
HOLDER SHEET B
2
E36-10
DFHR3B64ZA
LCD SIDE CUSHION A
2
E36-11
DFHR3506YA
LCD SIDE CUSHION C
2
E36-12
DFHR3507YA
LCD SIDE CUSHION D
1
E36-13
DFHR3G97ZA
LCD BACK SPACER TS
2
E36-14
DFHR3G99ZA
LCD REAR CUSHION F
2
E36-15
DFHR3H84ZA
LCD REAR CUSHION I
1
E36-16
DFMX0383TA
INSULATION PARTS
1
E401
DFUP1587ZA
FPC, AUDIO 40PIN
1
E402
DFUP1588ZA
FPC, IO 24PIN
1
Note : Important Safety Notice
Components identified by mark have special characteristics important for safety.
When replacing any of these components, use only manufacturer's specified parts.
Main Block Unit
REF. NO and OS
