Matsushita CF-19FHGAX User Manual
Page 35
■ Assembly of Touch Screen (Applicable Model : Touch Screen Model)
Avoid
running over.
Attach
the surface to the LCD Front.
Apply
the load 20 to 30N (2.0 to 3.0 Kgf) to the Cushions.
(Note)
OK
NG
T/S
T/S
Touch
Screen Ass'y
Attach
it to the front side.
(Using
the jig)
Dimensional
tolerance: 0.2
Details
of "A"
6
0.5mm
0
0.5mm
0
1mm
0
1mm
0
1mm
0
1mm
Back
Side
Match
to the wall of the
Cabinet.
0 to 0.5 mm
Match
to the marking line.
0.5 mm
Match
to the marking line.
0.5 mm
Ensure
4 and 5 do not run over the display side.
Touch
Screen Ass'y
Touch
Screen
Protect
Sheet
TS
FPC
Spacer
TS
Spacer A
TS
Spacer A
TS
Spacer B
TS
Spacer B
LCD
Side Cushion B
A
Laminate
Laminate
