■ Assembly of Tablet Latch Cover and Antenna Cover
10
Places
16
Places
Do
not forget fixing with screws.
Tablet
Lacth Cover
Antenna
Cover
Antenna
Cushion L
Screw
Screw
Screw
Screw
Press
and hold it against the cabinet,
and
fix it using the Screw.
Press
and hold it against the cabinet,
and
fix it using the Screw.
Press
and hold it against the cabinet,
and
fix it using the Screw.
Screw
Locations
Attach
it matching to the silk to put the
two-sided
tape on the Antenna side.
Fix in the order.
the
front side as well,
8
screws each side
Antenna
Cover
