■ Assembly of Display Unit

LCD

UNIT

A

Note
Avoid

any stress on the Cable.

Safety

Working

Details

of "A"

Screw

Screw

Screw

Screw

Screw

Screw

Screw

Screw

Order

of fixing

Close

the LCD hooking the

Hinge

on the Top Case, and

then

fold back.

Insert

all of antenna cables

into

the notch of the board.

LCD

Cable Insert Position

Set

to the Top Case Assy

Black/White

Blue/Gray

Brown

Pass

the Cable through

the

groove.

Note:

Running over

affects

the waterproof

performance..
